AFOX AFNIJ1900-2L

Model Name: AFNIJ1900-2L
Chipset: N/A
Socket: INTEL® Socket 1170
Supports Intel® Celeron® J1900 Processor Embedded
So-Dimm DDR3L 1333/1600MHz 1.35V
1 x Memory Slot (Max. up to 8GB)
Electromagnetic interference resistance
Strong environmental adaptability
High stability, dustproof and seismic resistance


HD Gallery

  • DESCRIPTION
  • SPECIFICATION
  • BIOS / DRIVERS UPDATE
  • REQUIREMENT

►So-Dimm DDR3L 1333/1600MHz support

►SATA 3Gb/s

►Gigabit LAN

►USB 3.0

►Microsoft Windows 10/11 compatible

Platform

INTEL® Socket 1170

Model Name

AFNIJ1900-2L

Chipset

N/A

CPU Supports

Intel® Celeron® J1900 Processor Embedded

FSB

1333/1600MHz

Memory

So-Dimm DDR3L 1333/1600MHz 1.35V (Memory up to 8GB)

Dimm

1 x Memory Slot (Max. up to 8GB)

Onboard Graphics

Integrated Graphics Processor

PCI/PCI-E Slots

N/A

SATA

1 x SATA2, 1 × MSATA

IDE

N/A

Audio

Realtek 662 on board, supports 6-channel audio-out

LAN

Realtek RTL8111 1000M lan onboard

Back Panel I/Os

1 x HDMI
1 x VGA
2 x USB2.0,  2 x USB 3.0
2 x LAN
2 x Audio

ON-Board Pinheaders/Connectors

2 x USB 2.0 pinheader (support additional 4 USB 2.0s)
2 x Front Panel
2 x COM pinheader
1 x Front Panel Audio pinheader
1 x VGA connector
1 x HDMI connector
1 x PWR DC
1 x 4G/WIFI

BIOS

UEFI BIOS

Mounting

4 mounting holes
Form Factor Nano Mini-ITX (12 x12cm)
