AFOX A88-MA2
Model Name: A88-MA2
Chipset:AMD® A88
Socket: AMD Socket FM2/FM2+
Supports the generation of AMD LGA FM2 / FM2+ Processors
Dual channel DDR3, two memory slots
1066/1333/1600MHz Memory up to 16GB
High speed USB interface
High quality audio special capacitor+independent audio block LED isolation line
Design of Gigabit high-speed network card
High definition interface＋multi-screen display
Keep fighting with ease
- DESCRIPTION
- SPECIFICATION
- BIOS / DRIVERS UPDATE
- REQUIREMENT
►AMD® A88
►Dual-Channel DDR3 1066/1333/1600MHz Memory up to 16GB
►SATA 3Gb/s
►Gigabit LAN
►PCI Express Architecture
►USB 3.0
|
Platform |
AMD Socket FM2 / FM2+ |
|
Model Name |
A88-MA2 |
|
Chipset |
AMD® A88 |
|
CPU Supports |
AMD LGA FM2 / FM2+ Processors: AD740X/A4-5300 (AD5300)/A10-5700/A8-5600/A10-5800/AD760KWOA44HL/A6-5400/A10-7800(AD785K)/A10-7800(AD7870K)/A8-7600(AD765K)/A8-7600(AD760B)/AD860K/AD840/A6-7400/A6-7480/A8-7680(CPU up to 95 watts) |
|
FSB |
1066/1333/1600MHz |
|
Memory |
Dual Channel DDR3 1066/1333/1600MHz |
|
Dimm |
2 x Memory Slots (Max. capacity of system memory 16GB) |
|
Onboard Graphics |
Integrated AMD APU graphics |
|
PCI/PCI-E Slots |
1 x PCI Express x16 slot, 1 x PCI x1 slot |
|
SATA |
4 x SATA2 |
|
IDE |
N/A |
|
Audio |
Realtek 662 on board, Supports 6-channel audio-out |
|
LAN |
Realtek RTL8105/8106 10/100Mbps Ethernet on board |
|
Back Panel I/Os |
1 x HDMI Port 1 x D-Sub (VGA) Port 1 x PS/2 Mouse Port 1 x PS/2 Keyboard Port 2 x USB 3.0 Ports 4 x USB 2.0 Ports 1 x RJ-45 LAN Port 3 x HD Audio Jack (Line in / Front Speaker / Microphone) |
|
ON-Board Pinheaders/Connectors |
1x USB 2.0 pinheader (supports additional 2 USB 2.0s) 1 x USB 3.0 pinheader (supports additional 2 USB 3.0s) 1 x Front Panel Audio pinheader |
|
BIOS |
UEFI BIOS |
|
Form Factor |
Micro-ATX (17*22cm) |
|
Mounting |
6 mounting holes |
|
Accessories |
1 x SATA II cable 1 x I/O Rear Panel 1 x User Manual 1 x Driver CD |
